Specification :
| Brand | Topshak |
| Model | NPS3010W |
| Input Voltage | 110V/220V Regulated ±10% 60Hz /50Hz |
| Plug | UK/US/AU Plug |
| Output Voltage | 0-30V |
| Output Current | 0-10A |
| Wattage | 300W |
| Three Displays | Current(0.01),Wattage(0.1),Voltage(0.1) Display |
| Line Regulation | ≦5mV |
| Load Regulation | ≦5mV |
| Recovery time | ≦500 μs(50% load change, minimum load 0.5A) |
| Ripple & Noise | ≦5mVrms, 100mVp-p |
| Temperature Coefficients | ≦100ppm/°C |
| Operation Temperature &Humidity | 0°C to 40°C, <80% |
| Storage Temperature & Humidity | -10°C to 70°C, <70% |
Features :
- With (click here)
- 110V/220V Regulated switching power supply.
- Continuous working,perfect line protection function.
- With fan, can reduce heat for long service life.
- With warm, overload, current limiting protections.
- The cooling system for intelligent temperature control fan.
- Apply for sticking technology small size, good appearance.
- Overvoltage protection, overcurrent protection, overheat protection, short circuit protection.
- Suitable for school, laboratory, workshop and various occasions which need to use DC Power Supply.
- This DC power supply can provide electronic devices of direct voltage from 0-30V and current from 0-10A.
- Can be regulated power supply using also can be used for current, voltage regulator, steady flow can be automatic conversion.
Package included:
1X110V/220V Adjustable DC Power Supply
1X Power Cord(UK/US/AU Plug)
1X Crocodile Clip
1X Warranty Card
1X English Manual
